Self-Propelled Modular Transporter (SPMT)

Self-Propelled Modular Transporters consist of different modules with 4, 5, 6 and 8 axle lines. Load capacity differs per version, with a maximum of up to 44 tons per axle line. Each module can be fitted with its own engine and control (steering) system. The modules can be connected side-by-side and/or head-to-tail, to form large ‘platforms on wheels’. SPMT’s have the possibility of 360 degree steering of the wheels. This allows carrousel and sideway movements. Their deck height can hydraulically be adjusted by approximately 60 cm., enabling vertical lifting or lowering of the load. Due to their variety of combinations, SPMTs can lift and move virtually every heavy load. These trailers are mainly used for on-site transportation over limited distances.
