Mammoet reveals design specifics of Focus crane

After the announcement that Mammoet has decided to develop the FOCUS30 in April this year, the company now has revealed more details of the 2500t class crane’s design in an animation featured on Mammoet’s YouTube channel.

The animation demonstrates how this new type of high-capacity crane can be erected vertically in a very small area. This makes it the ideal heavy-lift solution for efficient and safe project execution in limited and congested spaces, such as plants and inner cities.

Says Jacques Stoof, Director of Innovation and Market Development at Mammoet: “The animation shows how the main boom is erected vertically with the help of a climbing frame. Once the main boom is in place, the back mast can be installed vertically as well. This eliminates the need to sterilize larger parts of a plant area for crane assembly. Neither is there any more need to build over live pipe racks in a plant. All in all, the assembly process is less complex, safer and more efficient, and significantly reduces the costly area and downtime of assembling a crane.”

The animation further demonstrates how the crane’s upper structure is placed on a pedestal. This enhances its stability and lowers ground bearing pressures to less than 10 tons per square meter on a surface of just 30 by 30 meters. The animation also shows the variable super lift system, with a radius that can be adjusted under load from 16 to 30 meters. This will increase the crane’s flexibility, delivering a larger operational window, especially in congested areas.

“The FOCUS30 will set a new standard of heavy lifting in confined spaces,” continues Jacques Stoof. “The design that we demonstrate in this animation is based on numerous discussions with our customers in which we gained a good understanding of their current and future challenges. The FOCUS30 is a direct response to their need for greater lifting capacity and flexibility within limited and congested spaces. This innovation is a cost-saving solution for many of our customers within the power, petrochemical and civil sectors.”

Construction has started and the first FOCUS30 crane will be available in the second quarter of 2020.
